Summarize
Sine wave series inverter is one of the most advanced DC to AC conversion products in the world, it has the main advantages of high quality sine wave AC output, microcomputer control, humanness design, and it is simple, stable, no noise and no pollution. It is suitable use for areas without electricity, vehicles, ships, solar energy, wind turbine etc. The inverter can also supply AC voltage to all kinds of power tools, air conditioners, electric motors, refrigerators, fluorescent lights, televisions, electric fans and other power supply.
The inverter output waveform is sine wave; this kind of AC power is suitable for most industrial electronics and home appliances, the power supply features much better than other modified sine wave and square wave.
Features
* Faceplate show working status and fault type
* Over voltage under voltage automatic return to work after normal
* Manage charge and discharge electricity with many kinds and capability of accumulator.
* With three stage charges for battery choice
* Protect Inverter overload, under voltage, over voltage, over temperature, short circuit.
* High conversion rate, high instantaneous power and low no-load wastage
* Small size, high efficiency, quiet operation
Technical Data
|
Model |
TLS- 8KVA |
|
Rated power |
8000W |
|
Battery voltage |
192V, (220V, 240V) |
|
Maximum discharge current |
41A |
|
Output current |
36A |
|
Charge current |
10% according battery capacity |
|
Charge function |
Charger outside(can choose) |
|
Instant maximum power |
150% technical data, 10sec |
|
Output voltage |
220V AC ±3% |
|
Frequency |
50Hz±0.05Hz |
|
No-load power |
0.8A DC |
|
Waveform distortion（THD） |
≤5%(Linear load) |
|
Inverter efficiency |
≥85% |
|
Work environmental temperature |
-10℃~60℃ |
|
Work environmental elevation |
≤1000m | |
