Blind Rivet
UPTIME : 2010/3/29 20:47:35 / CLICKS :2712


Open Type Aluminum Blind Rivet（AA）


Standards: IFI-114 and DIN 73373

Finish: Zinc plated, Nickel plated

Material: mild steel, aluminum

High crimping force

Screw length can be varied

Just-in-time manufacturing capability to meet customers' requirements

Concurrent engineering capability on product design

D
/mm

L
/mm
Grip Plate Thickness
/mm

DK
/mm

H
/mm

W
/mm

Drill Dia
φ
Tensile
/N
Shear
/N
3.2
7
9
11
13

2.5-4.5
4.5-6.5
6.5-8.5
8.5-10.5
6
1
1.9
3.3
1045
698
4
6
8
10
13
16
18

1-3
3-5
5-7
8-10
10-12
11-13
8
1.4
2.2
4.1
1557
1000
4.8
7
9
11
13
14
16

1.5-3.5
3.5-5.5
5.5-7.5
7.5-9.5
8.5-10.5
10.5-12.5
12.5-14.5
9.5
1.5
2.6
4.9
2224
1401
5
6
8
11
13
16
18

0.5-2.5
2.5-4.5
5.5-7.5
7.5-9.5
10.5-12.5
12.5-14.5
9.5
1.5
2.8
5.1
2420
1480
