CWY(CVT)series high-availability anti-interference constant voltage transformer
UPTIME : 2010-8-24 10:01:59 / CLICKS :541

With features of isolation, anti-interference, little waveform distortion, wide range of voltage stabilization,automatic
protection against short circuit, rapid response, long life, etc, CWY(CVT) series high- availability anti  -interference
constant voltage transformer is a safe and reliable product provided for precious and precise equipment.

Application (CWY(CVT)series high-availability anti-interference constant voltage transformer)

For computer, test equipment, lighting system, safety alarming system,communication system, medical equipment,
duplicator,  family cinema equipment,  industry automatic equipment,  numeral control machine tool,  photographic
processing equipment, office equipment, etc.

Performance (CWY(CVT)series high-availability anti-interference constant voltage transformer)

lnput voltage
Single-phase 120V-300V
Output voltage
220V.accuracy±7%
lnput voltage
Single-phase-160V-264V
Output voltage
220V.accuracy±7%
lnput voltage
Single-phase 176V-264V
Output voltage
220V.accuracy±7%
lnput voltage
three-phase 208-520V
Output voltage
380V.accuracy2%~7%
lnput voltage
three-phase 266V-494V
Output voltage
380V.accuracy±2%
lnput voltage
Three-phase 304V-456V
Output voltage
380V.accuracy±1%
Frequency
50Hz±1Hz
Response time (jump of output± voltage110V)
≤30ms
Waveform distoriton
≤3%
Noise
<60dB(distance:1m)
Effciency
80%(full load)
it has short-circuit automatic protection,the output voltage steps down to zero when the load shows short circuit,however,when output short circuit takes 5min,it is not allowed to work continuously
Output voltage
220V.accuracy 2%-7%

Model and spec (CWY(CVT)series high-availability anti-interference constant voltage transformer)

Spec.(KVA)
Product size D×W×H(cm)
Weight(kg)
Spec.(KVA)
Product size D×W×H(cm)
WeightIkg)
Single-phase
CWY-0.3
37×17×20
21
Three-phase
CWY-1.5
57×27×43
80
CWY-0.5
33×27×29
27
CWY-3
70×29×47
195
CWY-1
45×25×45
40
CWY-6
77×49×40
330
CWY-2
49×25×45
60
CWY-9
89×49×45
580
CWY-3
60×32×77
90
CWY-15
89×56×51
650
CWY-5
60×32×47
120
CWY-20
106×64×56
900
CWY-10
86×67×117
330
CWY-30
106×64×56
1250
